EKE 1A

Gross weight

0.24 kg

Net weight

0.13 kg

EAN

5702428964319

Analog inputs (AI) [pc]

2 pc

Analog inputs type

Voltage

Approval

C-TICK
CE
EAC
LLC CDC EURO-TYSK
RoHS

Battery back-up [V] DC [Max]

24 V

Battery back-up [V] DC [Min]

18 V

Communication type

RJ11 (CAN) to User Interface

Digital inputs (DI) [pc]

3 pc

Digital outputs (DO) [pc]

1 pc

Display - option

MMIGRS2

Display on front

No

Enclosure rating note

IP40 for Housing

Equipment

Frequency [Hz]

50/60 Hz

Further information

Shared power supply
Signal share via hardwire

Gateway option

MMIMYK

Mounting method

DIN rail

Number of pressure sensors

1

Number of temperature sensors

1

Packing format

Multi pack

Pressure sensor support

Ratiometric 0.5 - 4 V DC

Product accessories

Electron. control accessories

Product features

Alarm management
Defrost Sequence
Ext. reference, SH control
Limitation functions
Manual operation
Preset OD
Reversible system with 1 EXV
Service mode
Start up
Superheat reference
Valve driver: Reference of OD

Product group

Electronic valve control

Product Language

Chinese
English
French
German
Italian
Portuguese
Russian
Spanish

Product name

Superheat controller

Programming tools

Koolprog

Quantity per packing format

16 pc

Serviceable

No

Supply voltage [V] AC

24 V

Supply voltage [V] DC

24 V

Temp. sensor configuration

S2

Temp. sensor support

NTC10000

Type

EKE 1A

Valve output type

ETS 100
ETS 25
ETS 50
ETS 6
